45 Ton Excavator Hydraulic Quick Hitch With Pins CE certified

Product Details

Place of Origin: Jiangmen, Guangdong

Brand Name: ZHONGHE

Certification: CE

Model Number: KJ001

Payment & Shipping Terms

Minimum Order Quantity: 1pcs

Price: Negotiate

Packaging Details: Bubble bag packaging, wodden case, iron support

Delivery Time: 5-10 work day

Payment Terms: T/T

Supply Ability: 200 Pieces / Month

Get Best Price
Highlight:

45 Ton Excavator Hydraulic Quick Hitch

,

Pins Excavator Hydraulic Quick Hitch

,

CE hydraulic quick hitch

Application:
Excavator Bucket Quick Hitch
Suitable Excavator(ton):
33-45T
Pin To Pin:
550-620 Mm
Forearm Open Width:
416-469 Mm
Retractable Distance Of Cylinder:
520-590 Mm
MOQ:
1 Set
Pin Diameter:
90-120 Mm
Top To Bottom Pin Distance:
360 Mm
Application:
Excavator Bucket Quick Hitch
Suitable Excavator(ton):
33-45T
Pin To Pin:
550-620 Mm
Forearm Open Width:
416-469 Mm
Retractable Distance Of Cylinder:
520-590 Mm
MOQ:
1 Set
Pin Diameter:
90-120 Mm
Top To Bottom Pin Distance:
360 Mm
45 Ton Excavator Hydraulic Quick Hitch With Pins CE certified

CE Proved 33-45T Excavator Coupler Hydraulic Quick Hitch With Pins For Excavator


Pls Click Here for Excavator Attachment Catalog.pd...


Excavator Hydraulic Quick Coupler



The coupler plate is designed to fit into the coupler body and is held in place by a locking mechanism. The locking mechanism typically consists of two pins that are inserted into holes in the coupler plate, securing it in place.

When the operator wants to attach a different bucket or attachment, they simply release the locking mechanism, remove the current bucket or attachment, and then attach the new one by aligning the coupler plate with the coupler body and reinserting the locking pins.

45 Ton Excavator Hydraulic Quick Hitch With Pins CE certified 0

45 Ton Excavator Hydraulic Quick Hitch With Pins CE certified 1



Excavator Quick Coupler Features



1. Increased productivity: The ability to switch between attachments quickly and easily can increase the productivity of the excavator, as operators are able to use the most suitable attachment for the task at hand.

2. Versatility: The quick coupler system allows excavator operators to use a variety of different attachments on the same machine, making the equipment more versatile and capable of performing a wider range of tasks.

3. Safety: The locking mechanism of the quick coupler system ensures that attachments are securely fastened to the excavator arm, reducing the risk of accidents or injuries caused by attachments coming loose during operation.



Item/Model Unit ZHMINI ZH45 ZH50/55 ZH60/65 ZH70/80 ZH90 ZH100/110
Suitable Excavator ton 1.5-4 4-7 5-8 9-19 17-23 23-30 33-45
Pin to Pin Center Distance mm 80-150 230-270 290-360 380-420 460-480 473-540 550-620
Forearm Open Width mm 80-140 155-170 180-200 232-315 306-340 375-411 416-469
Retractable Distance of Oil Cylinder mm 170-206 205-275 340-450 340-486 256-390 413-590 520-590
Top to Bottom Pin Distance mm 159 195 195 220 275 300 360
Pin Diameter mm 25-40 45-50 50-55 60-70 70-80 80-90 90-120
Norking Pressure bar 32-40 32-40 32-40 32-40 32-40 32-40 32-40
Working Flow lpm 10-20 10-20 10-20 10-20 10-20 10-20 10-20


45 Ton Excavator Hydraulic Quick Hitch With Pins CE certified 245 Ton Excavator Hydraulic Quick Hitch With Pins CE certified 3
45 Ton Excavator Hydraulic Quick Hitch With Pins CE certified 4

Please click here to add my facebook or contact me via WhatsApp: 0086 15362217237

Top picks:
1. Excavator rock bucket
2. Excavator tilt bucket
3. Excavator rock grab
4. Excavator log grapple


Company Advantages

45 Ton Excavator Hydraulic Quick Hitch With Pins CE certified 5
45 Ton Excavator Hydraulic Quick Hitch With Pins CE certified 6

45 Ton Excavator Hydraulic Quick Hitch With Pins CE certified 7


45 Ton Excavator Hydraulic Quick Hitch With Pins CE certified 8




Production Advantages

45 Ton Excavator Hydraulic Quick Hitch With Pins CE certified 9


Customer Feedback


45 Ton Excavator Hydraulic Quick Hitch With Pins CE certified 10
45 Ton Excavator Hydraulic Quick Hitch With Pins CE certified 11


Packing&Delivery

45 Ton Excavator Hydraulic Quick Hitch With Pins CE certified 12

Bubble bag packaging for most products.

Wooden case for little products, like buckets.
Iron frame support for boom arms.

The accessaries and package of excavator long boom arm are subjected to our final confirmation.
