Highlight:
Excavator Rock Hammer Hydraulic Breaker
, 45 ton Excavator Rock Hydraulic Breaker
, 180kg Excavator Rock Breaker
Mini Excavator Rock Hammer Hydraulic Breaker For 30 - 45ton
Mini Rock Breaker Hammer Excavator Rock Hydraulic Breaker for 30-45ton Excavator
2024 Zhonghe Machinery Catalogue 3M.pdf
If you would like to more details, pls contact me.
| Contact |
Ada |
| Tel/ Whatsapp |
0086 15322105263 |
| E-mail |
abby@excavatorboomarm.com |
Key components and characteristics of excavator rock breaker:
Hydraulic Power: Excavator rock breakers are powered by the hydraulic system of the excavator. They use the excavator's hydraulic power to deliver high-impact energy to break through tough materials.
Impact Energy: These attachments generate a high amount of impact energy, allowing them to break even the hardest rocks and concrete. The impact energy is produced by a piston striking a chisel or blunt tool at the end of the breaker.
Chisel or Blunt Tool: Excavator rock breakers typically come with interchangeable tools that can be either chisel-shaped or blunt. Chisel tools are suitable for breaking hard materials like rocks, while blunt tools are used for breaking concrete and pavement.
Attachment Mounting: Excavator rock breakers are attached to the excavator's arm or boom using a dedicated mounting bracket or a quick coupler system. This allows for easy installation and removal of the breaker attachment.
Control Mechanism: The operation of an excavator rock breaker is controlled by the excavator operator from the cab. The attachment is typically equipped with hydraulic hoses and control valves that are connected to the excavator's hydraulic system.
Impact Frequency and Power: Excavator rock breakers have adjustable impact frequency and power settings, allowing the operator to optimize the tool's performance based on the material being broken. Higher impact frequencies are suitable for softer materials, while lower frequencies are used for harder materials.
Size and Weight: Excavator rock breakers come in various sizes and weight classes to match different excavator models and applications. The size and weight of the breaker attachment must be compatible with the lifting capacity and reach of the excavator.
Versatility: Excavator rock breakers can be used for various applications, including rock excavation, demolition, quarrying, trenching, and road construction. They are versatile attachments that make the excavator a more efficient and versatile machine.
Safety Features: To ensure safe operation, excavator rock breakers are equipped with safety features such as overload protection, auto-shutdown systems, and noise reduction measures. These features help protect the operator and the excavator from potential risks.
|
Specification
|
Unit
|
Excavator Breaker
|
|
Body weight
|
kg
|
1590
|
|
Total weight
|
kg
|
3277
|
|
outline dimension(L*W*H)
|
mm
|
3460*665*840
|
|
Operating pressure
|
kg/cm2
|
170-200
|
|
oil flow range
|
I/min
|
200-250
|
|
Diameter of hose
|
inch
|
1-1/4
|
|
Diameter of tool
|
mm
|
165
|
|
Impact frequency
|
bpm
|
250-380
|
|
Suitable carrier
|
ton
|
30-40
|
1. We pack the products by simple pallet or case which is seaworthy.
2. Fast delivery time: 5-7 days for small quantity, and 20-30 days for container quantity.
3. We have a team specialized in packing and loading container, they have rich experience, and can load the max quantity products, which can help customer save the ocean freight.
Standard free spare parts
Two chisels, two hoses, one set of N2 charging kit with N2 bottle and pressure gauge, one tool box with maintenance tools and
operation manual as well.
Standard free spare parts
Double-layers stretch Film Inside, solid packaging with pallets in case the water leakage.in container.
Non-fumigation wooden case
Standard export wooden case, double reinforcement inside. No need for fumigation, free from your concerns of Customs inspection
and quarantine.
Q: Are you a manufacturer/factory?
A: Yes, we are a manufacturer established in 2018. Welcome to Zhonghe Machinery. We can provide more cost-effective attachments for construction machinery. Our principle is to manufacture the best products with first-class equipment. You can find various high-quality accessories suitable for all types of excavators, bulldozers, and loaders. We export our products to various parts of the world with the best quality and excellent service. We believe that you will be satisfied with our best after-sales service.
Q: Do you accept OEM?
A: Yes, we can provide OEM and customized manufacturing. Please send us the drawings so that we can produce the products according to your requirements.
Q: Can you give me some samples?
A: Sorry, we do not provide sample production as our materials are precious and the cost is relatively high. But we can provide you with many physical pictures and videos for your reference. Our product has a high annual sales volume and a high repurchase rate. You can completely trust us
Q: Are you sure your product is suitable for my excavator?
A: Our chisels can adapt to different excavators. Let me take a look at your model, we can provide you with the most matching product
